GPS-GT03A Gps Portable Tracker 2400Mah

GT03A Specification

GSM Specification

GSM frequency	850/900/1800/1900 MHz
GPRS	Class 12, TCP/IP
Memory	32+32Mb
Phase error	RMSPE<5,PPE<20
Max output	GSM850/GSM900:33±3dBm
	GSM1800/GSM1900:30±3Bm
Max frequency error	±0.1ppm


GPS Specification

GPS chipset	MTK high sensitivity chip
Frequency	L1,1575.42MHz C/A code
GPS channel	66
Location accuracy	<10 meters
Tracking sensitivity	-165dBm
Acquisition sensitivity	-148dBm
TTFF (open sky)	Avg. hot start≤1sec
	Avg. cold start≤35sec


Functional & Package

Voice monitor range	≤5 meters
Dust-waterproof level	IP65
Button	1xPower On/Off
Working voltage/current	3.7VDC/60mA
Charger voltage/current	5VDC/1A
Operating temperature	-20℃～ 70℃
Battery	2500mAh/3.7V
Charging period	4 hours
Standby time (Deep sleep mode)	20 days
Working time (GPS working mode)	30 hours
Dimension	91.5(L)57.0(W)24(H)mm
Weight	<100g/202g
