BLAUPUNKT Stockholm 400 DAB 1Din Car Stereo with CD Player / Bluetooth / AUX / USB

Bluetooth

• Telephony via int. or ext. microphone
• Audio streaming with ID3 title display
• Access to voice assistants (Siri, Google, Alexa)
• Wake up on call
• phone book access

Sound

• sound preset
• loudness
• 4-channel preamp output + 2 sub-out
• 4 x 50 watts

Generally

• Multicolor (7 colours)
• DIM function
• Persistent Storage
• IR remote controllable, RC-10 compatible
• SWC input (analog)

RADIO ANALOG / DIGITAL

• Tuner type: high-end automotive tuner Blaupunkt CODEM
• World tuner (switchable): EU, USA, South America, Thailand
• Frequency bands: FM, AM, DAB, DAB+
• FM frequency band: 87.5 – 108 MHz
• Frequency band MW: 531- 1602/ 530- 1710 kHz
• Channels (frequency band) DAB/ DAB+: 5A- 13F (174.928- 239.200 MHz)
• Station memory number: FM1, FM2, FMT (15x FM), AM1 (5x AM), DAB1-3 (15x DAB)
• Station memory levels can be deactivated: FM2, FMT, AM, DAB2, DAB3
• Station Display (PS): Yes
• Radio Text/ Radio Text Plus (RT/ RT+): Yes/ No
• Display DLS/ ENSEMBLE/ SERVICE: Yes/ Yes/ Yes
• Alternative Frequency Function (AF): Yes
• Traffic Information (TA) FM/ DAB: Yes/ Yes
• RDS Time (CT): Yes
• Enhanced Oth. netw. (EON): No
• Regional Function (REG): Yes
• Program Type Identification/ Search (PTY) FM/ DAB: Yes/ Yes
• Scrolling: Yes (once/repeating)
• Travelstore/ Storage Travelstore: Yes (5x FMT)
• Band Scan + Preset Scan FM/ DAB: Yes/ Yes
• Sensitivity (FM): Two levels (lo/ dx)
• Noise Rejection (FM): Yes
• Hi-Cut (FM): Yes (switchable in several stages)
• DAB-DAB Service following: Yes
• DAB FM Service following: Yes
• Service Scan: Yes
• Ensemble/ change of service: yes/ yes
• Service Browsing: Yes
• Frequency Response FM (Hz) -3dB: 30-15,000
• Frequency response DAB (Hz) +/- 3 dB: 20 ​​- 20,000

MEDIA PLAYER

• AUX rear: Yes (3.5 mm jack)
• AUX-IN automatic recognition/activation: no/manual, can be deactivated in the menu
• USB Front: Yes (Type A, covered socket)
• Rear USB: No
• Memory card reader: no
• Concealed Front Inputs: Yes (USB)
• Compatible formatting (USB): FAT16, FAT32, exFAT
• Maximum memory size (USB): > 128 GB
• Maximum number of files/folders (USB): > 20000
• CD drive (for CDDA, CD-R, CD-RW): Yes
• Playback formats: MP2, MP3, WMA, FLAC, M4A/AAC, WAV
• Display options (depending on file format): ID3V2 (title, artist, album), folder, file, playing time
• Folder & File Browsing: Yes
• Scrolling: Yes (once/repeating)
• iPod, iPhone control: Yes (via USB)
• Shuffle Folder/ Media: Yes/ Yes
• Repeat Title/ Folder/ All: Yes/ Yes/ Yes
• Introscan: Yes

BLUETOOTH*

• Telephone: yes
• Internal Microphone: Yes
• connection option ext. Microphone: Yes
• Answer/Reject call: Yes/Yes
• Access phone book: Yes (max. 1000 numbers)
• Audio streaming: Yes
• Audio streaming ID3 title display: Yes (title, artist, album, playing time)
• Scrolling: Yes (once/repeating)
• Access to language assistants (such as Siri, Google, Alexa): Yes
• Mobile Navigation Audio Mix: No
• Auto wake-up on call: yes (when radio off + ignition on)
• Quick pairing without PIN: Yes
• Auto Reconnect: Yes
• Bluetooth version: 5.0 LE
• A number of paired devices: max. last 5
• number concurrently Devices: max. 1
• Supported profiles: A2DP, AVRCP, HFP, SPP
• Audio codecs: AAC, SBC
• *Availability/support of the functions depends on the phone/app used!

SOUND

• Equalizer: Sound presets
• Bass/ Treble Adjustment: Yes / Yes (+/- 7 levels)
• Balance/ Fader: Yes / Yes (+/- 9 levels)
• HPF/ LPF: No
• Loudness: Yes
• Sound Presets: Rock, Pop, Classic
• Source-specific tone setting: Yes
• Speaker outputs (channels): 4
• Preamp outputs (channels, voltage): 4 (RCA, < 2V)
• Sub-Out (channels, voltage): 2 (RCA, < 2V, variable gain/ frequency)
• Max. power: 4 x 50 watts
• Sine output at 14.4 V: 4 x 24 watts (according to DIN 45324)

GENERALLY

• Display: LCD, negative, anti-reflective, wide angle, alphanumeric + symbols
• Illumination color display/buttons: multi color, 7 colors (white, green, yellow, red, purple, blue, light blue)
• Day/Night mode: Yes (manual/via dimmer connection)
• Brightness: Multi-level, variable (16 levels)
• Clock display: yes
• HMI languages: English, German
• Low standby current: Yes (< 3.5mA)
• Antenna inputs: FM DIN/ ISO (adapter), DAB SMB (DAB with 12V phantom power)
• Mute Input/Telephone Mute: Yes (Ground Active)
• Ext. hands-free microphone connection: Yes
• Remote controllable: Yes (IR sensor for RC-10 and card remote control)
• Steering Wheel Control (SWC): Yes (analogue, programmable, pre-programmed)
• Variable Scan Time: Yes (4, 8, 12, 16, 60s)
• Confirmation beep: Yes (can be deactivated)
• Control panel type: fixed panel
• Color panel/decor ring: black/black
• Software update: via USB
• Permanent Memory: Yes (Settings & Presets)
• Demo mode: Yes
• Weight: about 1.45kg
• Dimensions: housing 52 x 178 x 170mm, front 188 x 58mm (H x W x D)
• Operating voltage: 10.5 – 14.4 V
• Current consumption: in operation: < 10A, 10 sec after shutdown ACC: < 3.5 mA
