KENWOOD KMR-M508DAB Marine 1DIN Digital Media Receiver with Bluetooth / USB /DAB+
1DIN Digital Media Receiver with Bluetooth, DAB+ Radio & Alexa Voice Service
€215.00 including 23% VAT & Free Shipping
KENWOOD KMR-M508DAB Marine 1DIN Digital Media Receiver with Bluetooth / USB /DAB+
- Conventional car radios are unsuitable for maritime use because the electronics and mechanics cannot withstand water, salt or high humidity.
- Kenwood, therefore, offers a radio with special protection processes for boat installation that combines first-class sound, optimal ease of use and high material durability.
KMR-M508DAB
SB – iPhone – Bluetooth – 2x RCA (2.5V) – DAB+ – DSP/DTA – 13 band EQ
Marine Digital Media Receiver with Digital radio DAB+, Bluetooth technology & Amazon Alexa voice service.
Enjoy convenient operation. Crystal clear digital radio DAB+. Built-in Bluetooth technology for hands-free calling and music streaming, the ability to use your smartphone as a wireless remote control, and interactions with Amazon Alexa’s cloud-based voice service. The digital sound processor, Time Alignment and 13-band EQ ensure optimal sound adjustments.
Display / Cosmetic features:
- Fully detachable front panel.
- 2-line liquid crystal display.
- Vertical alignment display for high contrast & wide viewing angle.
- Variable key & display backlight illumination
- 2 zone colour concept.
- Brightness control.
- Manual & timer set dimmer control.
- Menu language: English(Default)/French/German/Russian/Spanish.
- ID3 Tag Language: English/French/German/Greek/Russian/Spanish.
- Demonstration mode.
- Dual Accent key (Telephone / Amazon Alexa voice service).
- Front AUX-in & illuminated USB port with anti-dust cover door.
- 12H/24H clock display.
Audio features:
- 4 x 50W max output power (MOS FET).
- 2 RCA pre-out (2.5V), front + rear or subwoofer (switchable).
- Front stereo mini jack AUX input.
- Digital Sound Processor (DSP) & Digital Time Alignment (DTA).
- 13-band equalizer (1x manual set + 8 pre-sets)
- Preset sound effects.
- 3-way X’over.
- Subwoofer setup & control.
- Touch sensor tone.
Digital Audio Broadcasting (DAB+) tuner.
- DAB & DMB audio support.
- 18 (3×6) DAB+ presets.
- Intelligent seek & ensemble seek, soft link, AF set.
- Multipass noise canceller.
FM (RDS) / AM (MW/LW) tuners:
- 18 (3×6) FM + 6AM presets.
- Local Seek, Auto memory, Regional, AF set.
Tuner features:
- Retains tuner presets without backup power.
- Mixed presets (6 digital and/or analogue (FM/AM) radio stations).
- TI, Traffic Information (FM & DAB).
- PTY search, ASW select, PTY Watch, Related service.
USB port features:
- High-speed USB 2.0.
- 1.5A Quick battery charge (BC1.2 compatible).
- MP3, WMA, AAC, WAV and FLAC music files playback
- Drive change.
- Last position memory / Resume play.
- Random & repeat play.
- iPod/iPhone USB direct control (iAP2).
Bluetooth features:
- High-quality wideband hands-free speech (HFP 1.7.1).
- Dual device connection for full-time HFP connection.
- Audio streaming (A2DP) – SBC & AAC audio codec.
- Music library Tag browsing(AVRCP 1.6.1).
- Easy pairing via USB.
- KENWOOD Remote App ready (download via App Store & Google Play).
- Music Mix (5 phones switchable music streaming).
- voice control
- Amazon Alexa voice service support.
- Noise reduction / Echo cancelling / Gain adjustment.
- Signal strength, battery level & pairing indicator.
- High-quality rear wired microphone included.
General features:
- Firmware update by USB.
- Mitsumi to ISO connector DC cord.
- Steering remote control wire for 3rd party interfaces.
- Less then 1mA dark current in Power Off mode.
- Backup memory of MENU settings without backup power.
- Power Off in standby mode: Off / 20min / 40min / 60min.
- Detachable faceplate.
- Short body (100mm depth) for easy installation.
- Conformally coated PCB for improved moisture resistance & corrosion.
Technical specifications
DISPLAY / GRAPHICAL USER INTERFACE:
- Display Type: 2 line / 13 + 4 digits x 13 segments LCD.
- Display Size (WxH): 80mm x 12mm.
- Backlight illumination: RGB LED (Default: Variable Scan).
- Colour zone: 2-Zone: All zone / Zone1 / Zone2.
- Brightness Control (Display & key): 0 ~ 31 steps.
- Dimmer Control (Display & key): Manual(On/Off) / Timer Set.
- Text scroll: Off / Auto / Once.
- ID3 Tag language support: English/French/German/Greek/Russian/Spanish.
- Menu language: English(Default)/French/German/Russian/Spanish.
- Date & Clock Display in Standby mode: • (Default Off)
- Demo mode: • (Default On).
DAB+ TUNER:
- DAB+ & DMB audio support. •
- Service list in alphabetical order: •
- BAND / Frequency range: BAND III (174.928MHz ~ 239.200MHz).
- Sensitivity: -100dBm
- Signal-to-noise ratio: 90dB
- Connector type: SMB
- Output Voltage: 12VDC
- Maximum current: < 100mA
- DAB Aerial: Optional
FM/AM TUNER:
- Reception type: FM / AM (MW/LW).
- Radio Data System (RDS): AF / EON / PI / PS / PTY / RT / TA / TP / TI.
- Radio Text Plus: •
- Presets: FM: 18 (3×6) + AM (1×6).
- Preset type: NORMAL (default) / MIX
- Automatic memory entry (AME): •
- Up / Down search: •
- Tuner preset memory w/o backup power: •
- FM Frequency Range: 87.5MHz ~ 108.0MHz (50kHz step).
- FM Usable Sensitivity (S/N 30dB): 6.2dBf (28.5μV/75Ω).
- FM Quieting Sensitivity (DIN S/N 46dB): 15.2dBf (1.58μV/75Ω).
- FM Frequency Response (±3.0dB): 30Hz ~ 15kHz.
- FM signal-to-noise ratio: 68.0dB (mono).
- FM Stereo Separation: 40dB (1kHz).
- MW Frequency Range: 531kHz ~ 1611kHz (9kHz step).
- MW Usable Sensitivity (S/N 20dB): 28.5μV
- LW Frequency Range: 153kHz ~ 279kHz (9kHz step).
- LW Usable Sensitivity (S/N 20dB): 45.0μV
usb:
- USB standard: USB1.1/ 2.0 (high speed).
- File system: FAT 12 / FAT 16 / FAT 32.
- MP3: Compliant with MPEG-1/2 Audio Layer-3.
- WMA: Compliant with Windows Media Audio.
- AAC: AAC-LC “.aac” & “.m4a” files.
- WAV: Linear PCM “.wav” files.
- FLAC: FLAC file (Up to 24bit / 96kHz).
- Maximum supply current: 1.5A Quick battery charge.
- Frequency response: 20 ~ 20kHz (± 1dB).
- Signal-to-noise ratio: 99dB (1kHz).
- Dynamic range: 93dB
- Channel separation: 90dB
- iPod / iPhone direct control: iAP2 over USB
BLUETOOTH:
- Version: Bluetooth 4.2.
- HFP (Hands-free protocol): High-quality wide band speech (HFP 1.7.1).
- Dual phone connection: •
- SPP (Serial Port Profile): •
- PBAP (Phonebook Access profile): V1.2
- A2DP (Advanced Audio Distribution Profile): SBC & AAC audio codec.
- AVRCP (Audio/Video Remote Control Profile): Music Library Browsing (V1.6.1).
- voice control: •
- Rear wired microphone: included (3m cable)
AUDIO:
- Max output power: 4 x 50W (MOSFET).
- Output power (DIN45324,+B=14.4V): 30W x 4.
- Subwoofer Level Adjustable: -50~+10.
- Equalizer (Manual set): 13 band graphic equalizer / 62.5Hz~16kHz.
- Equalizer Preset: Natural/Rock/Pops/Easy/Top40/Jazz/Powerful/User.
- Bass Boost: Off / +01 / +02 / +03 / +04 / +05.
- Loudness: Off / Low / High.
- Subwoofer set: On / Off.
- Fader position control: Rear 15 ~ 0 ~ front 15.
- Balance position control: Left 15 ~ 0 ~ right 15.
- X over network: tweeter / HPF front / HPF rear/subwoofer.
- Speaker size control: Front/rear / subwoofer.
- Sound reconstruction: •
- Space enhancers: •
- Sound Realizer: •
- Stage EQ – sound enhancement: •
- Drive EQ: •
- Pre-out: 2x RCA: Front + Rear or Subwoofer (switchable)
- Pre-out level: 2.5V
- Pre-out impedance: ≤ 600Ω
- Speaker Impedance: 4~8Ω
- AUX in: 3.5mm stereo mini jack.
- AUX maximum input voltage: 1000mV
- AUX Frequency response: 20 ∼ 20kHz (± 3dB).
- AUX Input Impedance: 30kΩ
- Touch Sensor Tone: •
GENERAL:
- Operating voltage: 14.4V (10.5 – 16V allowable)
- Maximum current consumption: 10A
- Dark Current consumption in “All Off” mode: < 1mA
- Installation Size (W x H x D): 1DIN, Short body: 182 x 53 x 100mm
- Net Weight (Trim Plate & Mounting Sleeve Incl. 0.7kg
- Firmware update: via USB
- Security System: Removable faceplate
- All Off Mode: 0 / 20min / 40min / 60min
- DC Cord: 15cm (ISO to Mitsumi connector)
- Wired Steering wheel Remote Ready: • (For third-party interfaces)
- Conformal Coated PCB •
